8 Port Network 2 Gigabit Ethernet Poe Switch

Basic Information
Place of Origin: Guangdong
Brand Name: BT-PON
Certification: CE
Model Number: 1620GB
Minimum Order Quantity: 20
Price: Negotiation
Supply Ability: 10000 Unit/Units per Month
MAC Address: 8K Power Supply: Internal Power Supply
Certification: FCC, Ce, RoHS, Sgs, BIS(ISI) Communication Mode: Full-Duplex & Half-Duplex
Transmission Rate: 12Gbps Function: POE
Feature: Low Power Consumption PoE Ports: 1-24 Port Support PoE
High Light:

8 Port Ethernet Poe Switch

,

Gigabit Ethernet Poe Switch

,

8 Port Gigabit Poe Switch

8 PORT NETWORK GIGABIT POE SWITCH + 2 GIGABIT ETHERNET PORT POE SWITCH



Product Description:

he switch complies with 802.3af/at PoE+ standards, supporting up to 30W on each PoE port, not to exceed the switch’s specific power budget. This PoE Switch features ten auto-detecting full/half-duplex ports with automatic crossover detection (MDI/MDI-X). The enables users to easily connect and supply power to PoE capable devices such as wireless Access Points (Aps), IP cameras, and IP phones. And it can also connect other Ethernet devices like computers, printers, and Network Attached Storage (NAS) to fit into any type of network application.



Features:



Product Parameter:



Network Standard IEEE 802.3,IEEE 802.3u,IEEE 802.3x, IEEE 802.3af,IEEE 802.3at
Port

• 4 * 10 / 100/1000Mbps RJ45 port

• 2 * 10 / 100/1000Mbps RJ45 uplink port

PoE Power Supply

• 4 * 10 / 100/1000Mbps RJ45 port supports PoE + power supply (Data / PoE)

• Maximum single port power supply is 30W

• The power supply of the whole machine is 120W

PoE Connection

• 1-4 ports support IEEE802.3af / at

• Support RJ45 network port 1/2 +, 3 / 6- line pair

Indicator Light

• Forwarding data port has a LINK / ACT.1000Mbps indicator

• The uplink port has two LINK / ACT.1000Mbps indicators

• PoE status indicator

• Machine power indicator

Performance

• Store and forward

• Support 2K MAC address table depth

• 12Gbps backplane bandwidth

Forwarding Rate

• 10Mbps: 14880pps / port

• 100BASE-T: 148800pps / port

• 1000BASE-T: 1488095pps/port

Port Function

• Fast and forward, MAC automatic learning and aging, power supply priority mechanism

•IEEE802.3X full-duplex flow control and Backpressure half-duplex flow control

Use Environment • Working temperature: -10 ℃ --55 ℃
Power Supply

• Internal power supply

INPUT:110VAC-265VAC,47HZ-63HZ

OUTPUT:DC48V-2.5A

120W





FAQ:

1.Can I get a sample free?
Yes,you need place sample order to us, and we will reduce from next order .
2.How do I know your products are original and brand new ?
We guarantee products from our company are original and brand new.
We are the key distributor of Huawei,ZTE,Fiberhome, who get special offer and technical support from them. Each model has S/N number and we will send you the S/N list to you after shipping .You can confirm with manufactures.
You will get competitive price and professional technical supports.
3.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
4.How can we place order?
Comfirm PI — Got the deposit — Arrange production/delivery
After we made agreement on the product's parameters, we will make proforma invoice for your confirmation. When we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if not, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
5.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. Usually it takes about 7 workdays to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
6.What's your products' advantages ?
A. Good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing, assemble, packing and shipping.
D. Good after-sale service. Professional online technical support can be provided. Moreover, if any problem of the goods, we will help to solve the problem or provide replacement of the goods.
