10KM HUAWEI 100G SFP Optical Transceiver

Basic Information
Place of Origin: Guangdong
Brand Name: BT-PON
Certification: CE
Model Number: GE-LSM40-B
Minimum Order Quantity: 100
Price: Negotiation
Supply Ability: 10000 Unit/Units per Month
Application: Telecommunication Rate: 1.25G
Place Of Origin: China Model Number: GE-LSM40-B
Type: FTTx Solutions Wavelength: 850nm/1310nm/1550nm
Distance: 2km Port: LC
High Light:

100G SFP Optical Transceiver

,

10KM SFP Optical Transceiver

,

10KM SFP Transceiver Module

Transceiver SFP HUAWEI 100G SFP fiber Optical Transceiver 100G 10KM



Product Description:

SFP, short for Small Form-factor Pluggable, aka Mini-GBIC, is a compact optical transceiver module used in optical communications. The SFP transceiver modules are designed to support SONET/H, Fast Ethernet, Gigabit Ethernet, Fibre Channel and other communications standards.BT-PON manufactures and supplies a complete range of SFP transceiver modules which can be Customized.



Features:

The optical output can be disabled by a TTL logic high-level input of Tx Disable,and the system also can disable the module via I2C. Tx Fault is provided to indicatethat degradation of the laser. Loss of signal (LOS) output is provided to indicate theloss of an input optical signal of receiver or the link status with partner. The systemcan also get the LOS (or Link)/Disable/Fault information via I2C register access.

Notes:

1. Circuit ground is internally isolated from chassis ground.

2. Laser output disabled on T DIS >2.0V or open, enabled on T DIS <0.8V.

3. Should be pulled up with 4.7k - 10kohms on host board to a voltage between 2.0V and3.6V.

MOD_DEF(0) pulls line low to indicate module is plugged in.

4. This is an optional input used to control the receiver bandwidth for compatibilitywith multiple data rates (most likely Fiber Channel 1x and 2x Rates). If implemented,the input will be internally pulled down with > 30kΩ resistor. The input states are:

Low (0 – 0.8V): Reduced Bandwidth

(>0.8V, < 2.0V): Undefined

High (2.0 – 3.465V): Full Bandwidth

Open: Reduced Bandwidth



Product Parameter:



Material
Metal
Color
Silver
Data Rate
10Gb/s
Weight
20g
Fiber Interface
LC (SC/ST/FC optional)
Fiber Type
Simplex, Duplex / Single Mode, Multi mode
Distance
300M,10KM, 20KM, 40KM, 80KM, 100KM,...
Wavelength
850nm, 1310nm, 1550nm
Operating Temperature
0-70℃
Ethernet Interface
one UTP RJ45 interface
Applicable Optical Cable
10G Ethernet
10G Fiber Channel
Data Center
Other Optical Links
Note : This SFP module compatible with CISCO, HUAWEI, JUNIPER, ZTE, D-LINK, HP,...



FAQ:

1.Can I get a sample free?
Yes,you need place sample order to us, and we will reduce from next order .
2.How do I know your products are original and brand new ?
We guarantee products from our company are original and brand new.
We are the key distributor of Huawei,ZTE,Fiberhome, who get special offer and technical support from them. Each model has S/N number and we will send you the S/N list to you after shipping .You can confirm with manufactures.
You will get competitive price and professional technical supports.
3.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
4.How can we place order?
Comfirm PI — Got the deposit — Arrange production/delivery
After we made agreement on the product's parameters, we will make proforma invoice for your confirmation. When we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if not, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
5.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. Usually it takes about 7 workdays to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
6.What's your products' advantages ?
A. Good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing, assemble, packing and shipping.
D. Good after-sale service. Professional online technical support can be provided. Moreover, if any problem of the goods, we will help to solve the problem or provide replacement of the goods.

10KM HUAWEI 100G SFP Optical Transceiver 010KM HUAWEI 100G SFP Optical Transceiver 110KM HUAWEI 100G SFP Optical Transceiver 2
