||Typical Splice Loss:
|Tube Heating Time:
|Typical Splice Time:
|Place Of Origin:
Auto Alignment Fiber Optic Fusion Machine,
Mini Fiber Optic Fusion Machine,
6 seconds Fiber Fusion Splicer
MINI AUTOMATIC CORE ALIGNMENT OPTICAL FIBER FUSION SPLICER SPLICING MACHINE
Optical fiber welding machine is mainly used in the construction and maintenance of optical fiber optic cable. The general working principle is to use high voltage electric arc to melt the two fiber sections, while using the high-precision motion mechanism to gently push the two fibers together into one to achieve the coupling of the fiber mode field.
- PAS alignment system
- Splicing 6 sec., heating 12 sec.
- Fast boot technology
- More than 300 times splicing and heating
- Resist dust, rain, wind, and shock
- Fiber type identify, AUTO splicing mode
- Easy to change electrode and fiber holder
- High speed USB, maintenance via the Internet
||SM, MM, DS, NZDS
||Manual, Half Auto, Auto
||Core to Core Alignment by PAS technology
||Cable indoor and 0.25mm,0.9mm fiber, SC connector(option)
|Fiber Image/ Magnification
||5 inch digital high-quality LCD screen
||Standard 2N (option)
|Heat Shrinkable Sleeve
||60mm, 40mm and serials heat Shrinkable Sleeve
200 cycles splicing and heating, 3 hours charging time
( splicing and charging at same time)
||Cycling charge 300-500 times, easy to replace battery
||3000, easy to replace electrodes
||USB Convenient data download and software update
Built in high brightness, wide range of lights, easy to operate at
Built in lithium battery 5200mAh 11.1V; external adapter, input: A
C100-240V, output: DC13.5V/4.5A
0-5000m above sea level, Temperature: -10-60℃,
Humidity:0~95%RH (No dew)
|Weight (including battery)
||2.1 KG (including battery)
1.Can I get a sample free?
Yes,you need place sample order to us, and we will reduce from next order .
2.How do I know your products are original and brand new ?
We guarantee products from our company are original and brand new.
We are the key distributor of Huawei,ZTE,Fiberhome, who get special offer and technical support from them. Each model has S/N number and we will send you the S/N list to you after shipping .You can confirm with manufactures.
You will get competitive price and professional technical supports.
3.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
4.How can we place order?
Comfirm PI — Got the deposit — Arrange production/delivery
After we made agreement on the product's parameters, we will make proforma invoice for your confirmation. When we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if not, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
5.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. Usually it takes about 7 workdays to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
6.What's your products' advantages ?
A. Good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing, assemble, packing and shipping.
D. Good after-sale service. Professional online technical support can be provided. Moreover, if any problem of the goods, we will help to solve the problem or provide replacement of the goods.
